SFP-GE-SX-MM850

P/N : SFP-GE-SX-MM850

● Supports 1.25Gbps/1.0625Gbps bit rates
● Duplex LC connector
● Hot pluggable SFP footprint
● 850nm VSCEL laser transmitter and PIN photo-detector
● Applicable for 550m on 50/125µm, 300m on 62.5/125µm MMF connection
● Low power consumption, < 0.5W
● Digital Diagnostic Monitor Interface
● Compliant with SFP MSA and SFF-8472
● Very low EMI and excellent ESD protection
● Operating case temperature:
Commerical:0 to 70 °C Industrial:-40 to 85 °C

If you want to know more about this product, please send us an email. We will get in touch with you immediately.

Overview

1. Gigabit Ethernet
2. Fiber Channel
3. Switch to Switch interface
4. Switched backplane applications
5. Router/Server interface
6. Other optical transmission systems

Features

● Supports 1.25Gbps/1.0625Gbps bit rates
● Duplex LC connector
● Hot pluggable SFP footprint
● 850nm VSCEL laser transmitter and PIN photo-detector
● Applicable for 550m on 50/125µm, 300m on 62.5/125µm MMF connection
● Low power consumption, < 0.5W
● Digital Diagnostic Monitor Interface
● Compliant with SFP MSA and SFF-8472
● Very low EMI and excellent ESD protection
● Operating case temperature:
Commerical:0 to 70 °C Industrial:-40 to 85 °C

Parameter

SFP Dual-fiber Optical Transceivers
Part Number	SFP-GE-SX-MM850
Trustnuo Part Number	TNSP8512L-CD550
DESCRIPTION	1G Multi-Mode Dual-fiber 850nm 550M
Data Rate (Mbps)	1250
Wavelength (nm)	850
Distance	550M
Optical Power (dBm)	-10~-3
Source	VCSEL
Sensitivity (dBm)	<-18
Receiver	PIN
Connector type	LC

Download

Datasheet-1.25G_SFP_850nm_550m
