SFP-10G-BX20D

SFP-10G-BX20D

Products > Transceiver > 10G BiDi >

SFP-10G-BX20D

P/N : SFP-10G-BX20D

QSFP28 MSA compliant
Compliant to IEEE 802.3bm 100GBASE-SR4
Up to 28Gb/s data rate per channel
Up to 100m OM4 MMF transmission
4 independent full-duplex channels
Operating case temperature: 0 to 70℃
Single 3.3V power supply
Maximum power consumption 2.5W
MTP/MPO optical connector
RoHS-6 compliant

If you want to know more about this product, please send us an email. We will get in touch with you immediately.

Overview

The QSFP28 is designed to carry 100 Gigabit Ethernet, EDR InfiniBand, or 32G Fibre Channel.

Sometimes this transceiver type is also referred to as "QSFP100" or "100G QSFP" for sake of simplicity.

100G QSFP28 optical transceiver includes SR4, AOC, CWDM4, PSM4, LR4 and ER4 Lite series.

Features

QSFP28 MSA compliant
Compliant to IEEE 802.3bm 100GBASE-SR4
Up to 28Gb/s data rate per channel
Up to 100m OM4 MMF transmission
4 independent full-duplex channels
Operating case temperature: 0 to 70℃
Single 3.3V power supply
Maximum power consumption 2.5W
MTP/MPO optical connector
RoHS-6 compliant

Parameter

10G SFP+ BIDI Optical Transceivers
Part Number	SFP-10G-BX20D
Trustnuo Part Number	TNSB321XL-CD204
DESCRIPTION	10G Single-Mode Single-fiber BiDi T1330/R1270 20KM
Data Rate (Mbps)	10G
Wavelength (nm)	TX1330/RX1270
Distance	20KM
Optical Power (dBm)	-3~+6
Source	DFB
Sensitivity (dBm)	<-14
Receiver	PIN
Connector type	LC/PC
